Five Tube Flowmeter

Five Tube Flowmeter
Business Type Manufacturer, Exporter, Supplier
Oxygen Inlet 6 mm Festo connection from rear bottom ,(Straight)
N2o Inlet 6 Mm Festo Connection from Rear Bottom ,(straight)
Air Inlet 6 Mm Festo Connection from Rear Bottom ,(straight)
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Mixed Gas Outlet
6 Mm Festo Connection from Rear ,Top,(straight)
Control Knob Oxygen
Aluminium with Special Profile as per Iso 5358,
Control Knob N2O
Aluminium Serrated, Serration Depth <1mm, Knob Dia Lower Than Oxygen Knob Dia
Control Knob Air
Aluminium, serrated, serration depth <1mm, knob dia lower then Oxygen knob Dia.
Working pressure (max)
420 kPa (N2O, O2 &AIR)
Oxygen Tube Range Low Flow
0.1 – 1 L/min, with Graduations in Lpm Unit
Oxygen Tube Range High Flow
1 – 10 L/min, with Graduations in Lpm Unit
N2o Tube Range Low Flow
0.1 – 1 L/min, with Graduations in Lpm Unit
N2o Tube Range High Flow
1 – 12 L/min, with Graduations in Lpm Unit
Air Tube Range of Flow
0.1 – 15 L/min Graduations in Lpm Unit
Metering Tube
Borosilicate Glass.
Float
Aluminium-is-6063,Anodised Red –for O2, N2o & Air
Accuracy (o2, N2o & Air)
As per Iso-5358
Tube Length (o2, N2o & Air)
220 Mm
Markings/identification
Float Mark On Tubes & other Markings as per Iso 5358
Mounting
Panel Mounting, as per Drawing
Housing
Aluminum Frame, Acrylic Front, Background On White Acrylic Sheet.
Material of Construction
Brass-is-319 Natural Colour/aluminium Is-6063 Anodized Natural, O Rings & Washer Epdm
Tube Fitting Arrangement
Left-o2, Middle-n2o, Right –air (o2.lf-o2.hf) –(n2o.lf-n2o.hf)- (air)
Hypoxia Unit
Geared Type Fitted with the Frame,
N2o Cutoff
Built-in Fitted At Back
Oxygen / N2o Ratio
30 + 5% of O2 At all Settings After N2o Flow Opening.
Labels for Control Knob-o2/n2o/air
O2-black On White Back Ground/n2o-white On Blue Back Ground /air-white On Black Back Ground.
Compliance To
Iso-5358, Rohs
Download
Download 01

Anaesthetic flowmeters are available in 2 – 5 tubes versions.  The flowmeters (2-5 tube versions) can be supplied with or without Anti Hypoxia Device.

The housings are made from Aluminum and fitted with fine adjustment valves for easy control of the anaesthetic gases. The front cover is  made from moulded acrylic. The devices have a phosphorescent “glow in the dark” (normally white) background for easy reading even in case of sudden darkness.

The knobs are made from finest quality ABS. The Oxygen knob has a touch coded profile and all the knobs are colour coded as per ISO 5358 requirements.

Internal gas connections are made using polyurethane tubes and Festo type connections. A non return valve in the downstream of the AHD ensures no flow of N2O in the respiratory circuit in the event of single fault condition when Oxygen line gets blocked.

Various options of inlet and outlet connections are available
